Sonraíocht
| Sraith Táirgí | Transceiver Optúil Snáithín | Uimhir HTFPart | HTSF-C1G51ZC |
| Fachtóir Foirm | CWDM SFP | Ráta Sonraí | 1.25 Gb / s |
| Tonnfhad | 1270 ~ 1610 nm | Cineál Snáithín | SMF |
| Fad Max | 80 km | Comhpháirteanna Optúla | DFB / PIN |
| Cumhacht Tarchuradóra | 0 ~ 5dBm | Cóimheas díothaithe | GG gt; 9dB |
| Íogaireacht an Ghlacadóra | GG lt; -26 dBm | Ró-ualach Glacadóra | GG gt; 0 dBm |
| Ceanglóir | Duplex LC | Diagnóisic DhigiteachMonitoring | Sea |
| Comhshaol | Oibriúcháin: 0 ° C go 70 ° C. Stóráil: -40 ° C go 85 ° C. | Meáchan | 0.025 kg |
| Iarratas | Cainéal Snáithín 1x, Athraigh go Comhéadan Athraigh Ethernet Gigabit, Feidhmchláir Backplane Athraithe Comhéadan Ródaire / Freastalaí, Naisc Optúla Eile | Comhlíonadh | IEC / EN 61000-4-2, IEC-60825 FDA 21CFR 1040.10 agus 1040.11 RoHS |
Conas a mhonaraíonn HTF an modúl optúil?
1.25Gb / s SMF 80km CWDM 1270 ~ 1610nm Modúl Transceiver Optúil SFP ZX
Is éard atá i HTSF-C1G51ZC HTF modúl transceiver SFP ardfheidhmíochta agus costéifeachtach CWDM (Ilphléacsú garbh-Tonn-Roinn) le haghaidh Ethernet Gigabit 1000BASE-ZX agus feidhmchlár Cainéal Snáithín 1G, a sholáthraíonn réitigh chumarsáide ard bandaleithid ardchumais do líonraí optúla ilphléacsáilte.
Soláthraíonn an modúl transceiver SFG 1G CWDM seo achar tarchuir 80km thar snáithín mód aonair. Gnéithe sé tarchuradóir CWDM DFB an-iontaofa agus fótachóode PIN isteach i gceanglóir optúil LC déphléacsach. Tá 18 tonnfhad lárionaid ar fáil ó 1270nm go 1610nm le gach céim 20nm.
Ina theannta sin, rinneadh modúl HTSF-C1G51ZC CWDM SFP a chomhtháthú le comhéadan monatóireachta diagnóiseach digiteach feabhsaithe (DDMI) in aghaidh SFF-8472, a sholáthraíonn monatóireacht fíor-ama ar theocht an transceiver, an claonadh claonta léasair, an chumhacht optúil, an chumhacht optúil agus an transceiver. voltas soláthair. Déantar na paraiméadair seo a chalabrú go hinmheánach de réir réamhshocraithe.
Úsáideann an transceiver 1G CWDM SFP ZX úsáidí le CWDM Multiplexer / Demultiplexer (CWDM Mux / Demux) a dhíolann HTF ar leithligh.
Gnéithe
• Tacaíocht a thabhairt do suas le naisc sonraí 1.25Gb / s
• Lorg an SFP te-pluggable
• Comhlíonadh le caighdeán MSA SFP
• Suas le 80km ar SMF 9 / 125µm
• Tarchuradóir 18-Tonnfhad CWDM DFB ó 1270nm go 1610nm, le céim 20nm
• Tacú le diagnóisic dhigiteacha, a chomhlíonann SFF-8472
• Soláthar cumhachta aonair 3.3V
• Ceanglóir LC Duplex
• diomailt ísealchumhachta
• Soláthraíonn imfhálú miotail IEA níos ísle
• Comhlíontach le ROHS agus Saor ó Luaidhe
Ordering Eolas
| Uimhir Chuid HTF | Cur síos |
| Teocht Tráchtála (Cás Oibriúcháin): 0 ℃ ~ +70 ℃ | |
| HTSF-C1G27ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1270nm, 80km, LC, DDM |
| HTSF-C1G29ZC | Modúl Transceiver SFP CWMM 1.25Gb / s, SMF, 1290nm, 80km, LC, DDM |
| HTSF-C1G31ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1310nm, 80km, LC, DDM |
| HTSF-C1G33ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1330nm, 80km, LC, DDM |
| HTSF-C1G35ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1350nm, 80km, LC, DDM |
| HTSF-C1G37ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1370nm, 80km, LC, DDM |
| HTSF-C1G39ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1390nm, 80km, LC, DDM |
| HTSF-C1G41ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1410nm, 80km, LC, DDM |
| HTSF-C1G43ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1430nm, 80km, LC, DDM |
| HTSF-C1G45ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1450nm, 80km, LC, DDM |
| HTSF-C1G47ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1470nm, 80km, LC, DDM |
| HTSF-C1G49ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1490nm, 80km, LC, DDM |
| HTSF-C1G51ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1510nm, 80km, LC, DDM |
| HTSF-C1G53ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1530nm, 80km, LC, DDM |
| HTSF-C1G55ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1550nm, 80km, LC, DDM |
| HTSF-C1G57ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1570nm, 80km, LC, DDM |
| HTSF-C1G59ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1590nm, 80km, LC, DDM |
| HTSF-C1G61ZC | Modúl Transceiver SFP 1.25Gb / s CWDM, SMF, 1610nm, 80km, LC, DDM |
| Teocht Tionscail (Cás Oibriúcháin): -40 ℃ ~ +85 ℃ | |
| HTSF-C1G27ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1270nm, 80km, LC, DDM |
| HTSF-C1G29ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1290nm, 80km, LC, DDM |
| HTSF-C1G31ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1310nm, 80km, LC, DDM |
| HTSF-C1G33ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1330nm, 80km, LC, DDM |
| HTSF-C1G35ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1350nm, 80km, LC, DDM |
| HTSF-C1G37ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1370nm, 80km, LC, DDM |
| HTSF-C1G39ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1390nm, 80km, LC, DDM |
| HTSF-C1G41ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1410nm, 80km, LC, DDM |
| HTSF-C1G43ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1430nm, 80km, LC, DDM |
| HTSF-C1G45ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1450nm, 80km, LC, DDM |
| HTSF-C1G47ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1470nm, 80km, LC, DDM |
| HTSF-C1G49ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1490nm, 80km, LC, DDM |
| HTSF-C1G51ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1510nm, 80km, LC, DDM |
| HTSF-C1G53ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1530nm, 80km, LC, DDM |
| HTSF-C1G55ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1550nm, 80km, LC, DDM |
| HTSF-C1G57ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1570nm, 80km, LC, DDM |
| HTSF-C1G59ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1590nm, 80km, LC, DDM |
| HTSF-C1G61ZI | 1.25Gb / s Transceiver Tionscail CWDM SFP, SMF, 1610nm, 80km, LC, DDM |
